Home / Lighting Controls / Dynalite Networked Control System / Relay Controllers / DDRC1220FR-GL Relay Controller
DDRC1220FR-GL
  • DDRC1220FR-GL
  • DDRC1220-FR Dimensions
  • DDRC1220FR Top

DDRC1220FR-GL Relay Controller

The Philips Dynalite DDRC1220FR-GL is a 12 channel feed through relay.

Category: Relay Controllers
  • Description
  • Features
  • Specifications
  • Schematic
  • Downloads

Robust control of switched loads

The Philips Dynalite DDRC1220FR-GL provides control of any type of switched load. All types of switched loads up to 20 A inductive are supported. The maximum load may be limited by 500 A inrush rating.

• Feed-through power circuit design — Electrically equivalent to a 12 pole contactor, with the added advantage of each pole being separately controllable via the DyNet network.

• Flexible mounting solution — A DIN-rail mountable device, designed to be installed into the distribution board supplying power to the controlled circuit.

• Inbuilt diagnostic functionality — Features circuit run time tracking on each channel and Device Online/Offline status indication.

• Multiple wiring schemes supported — Controls Single Phase and Neutral or Three Phase and Neutral (Star) wiring configurations.

• Hardware override — Service override switch accessible from front panel.

Item Specification Details
Input Voltage 100 – 240 VAC 50 / 60 Hz Single Phase @ 0.25 A
DyNet DC Supply 12 V @120 mA (supply for approx 6 user interfaces)
Outputs 12 x switched feed-through outputs @ 20 A (inductive)
Electrical Maximum device load 180 A
Single Phase and Neutral
Supported wiring schemes Three Phase and Neutral (Star)
Maximum device load 180 A
Rated switch current: 50 A resistive
Relays 20A lighting load
Rated inrush current: 500 A
Control Inputs/Outputs One DMX512 / RS-485 DyNet serial port
One programmable dry contact AUX input
Control User Controls Manual override switch for each channel
Service switch
Diagnostic LED
Internal Controls Programmable Logic Controller
Preset Scenes 170
Diagnostic Functions Device online/offline statu
Ciruit run time tracking on each channel
Network Watchdog
Supply Terminals Line, Neutral, Earth
1 x 4 mm² maximum conductor size
Output Terminals Line In, Line Out for each channel
1 x 4 mm² maximum conductor size
Physical Dimensions (H x W x D) 93 mm x 215 mm x 64 mm
Packed Weight 1.1kg
Construction Polycarbonate DIN-rail enclosure (12 unit)
Operating Conditions Temperature:  0 to 50° C ambient
Humidity:  0 to 95% non-condensing
Storage & Transport Temperature:  -25 to 60°C ambient
Humidity:  0 to 90% non-condensing
Certification Certification CE, RCM
Options & Ordering Standard Product DDRC1220FR-GL (Philips 12NC 913703052309)

  Download data sheet
