DDBC516FR
  • DDBC516FR
  • DDBC516FR Dimensions

DDBC516FR-Signal Dimmer Controller

Register to view LIST pricing & stock availability, for special trade pricing please contact us and we will setup the appropriate discounts for your account.

Register to add to cart

5 Channel Flexible controller for 1-10 V and DALI drivers.



SKU: DDBC516-FR Category: DALI - DSI - 0-10v Dimmer Controllers Brand: Dynalite
  • Description
  • Features
  • Schematic
  • Downloads

Signal Dimmer Controller

Flexible control of 1-10 V and DALI drivers

The Philips Dynalite DDBC516FR is a five channel device for controlling DALI drivers. Each control output is selectable to DALI broadcast, DALI addressed, 1-10V or DSI.

  • Multiple protocols supported – Each of the five control outputs supports DALI broadcast (maximum ten DALI loads/channel), DALI addressed (maximum ten DALI loads/channel), 1-10V (maximum 10 mA sink or source/channel) or DSI (maximum five DSI loads/channel).
  • Built-in energy savings – Control signals can be programmed to operate in tandem with five internal switched outputs, which will automatically isolate the power circuit when all associated channels are at 0%. This is a useful feature as DALI drivers still draw significant power when lamps are turned off via a DALI command.
  • Integral DALI bus power supply – Removes the need for an additional external device.
  • Flexible mounting solution – A DIN-rail mountable device, designed to be installed into the distribution board supplying power to the controlled circuit.
  • Inbuilt diagnostic functionality – Features lamp and driver failure reporting, driver run time tracking for each driver and the switched output, as well as Device Online/Offline status indication.

  Download data sheet
